Siemens 7XT3300-0 A00 Series User Manual

English 7XT3300-0*A00
42 C53000-B1175-C129-1
Blocking Input
Terminal points 6 and 8
Switching threshold adjustable voltage range with jumper
- for control voltages DC 24 V,
DC 48 V,
DC 60 V DC 19 V: U
high
≥ DC 19 V, U
low
≤ DC 10 V
- for control voltages DC 110 V
DC 125 V
DC 220 V
DC 250 V DC 88 V: U
high
≥ DC 88 V, U
low
≤ DC 44 V
Permissible voltage, continuous DC 300 V
Signal relay
Terminal points 5, 7 and 9
Switching capacity MAKE 30 W/VA
BREAK 20 VA
30 W resistance load
25 W at L/R ≤ 50 ms
Switching voltage DC 24 V to DC 250 V
AC 24 V to AC 230 V
Permissible current 1 A permanent
Permissible Ambient Temperatures
with R
L
< 5 Ω≤ 55 °C or ≤ 131 °F
with R
L
> 5 Ω≤ 70 °C or ≤ 158 °F
NOTE
R
L
describes the load resistance at the bandpass 7XT34 output (see
figure 10).
