Mechanical stress tests
Vibration and shock tests during stationary operation
Vibration and shock stress during transport
Standards IEC 60255-21 and IEC 60068
Vibration
IEC 60255-21-1, Class 2
IEC 60068-2-6
sinusoidal
10 Hz to 60 Hz: ±0.075 mm amplitude;
60 Hz to 150 Hz: 1 g acceleration
Frequency sweep 1 octave/min,
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1
IEC 60068-2-27
half-sine shaped
Acceleration 5 g, duration 11 ms,
3 shocks each in both directions of the 3 axes
Seismic vibration
IEC 60255-21-3, Class 1
IEC 60068-3-3
sinusoidal
1Hz to 8Hz:±3.5 mm amplitude (horizontal axis)
1 Hz to 8 Hz: ±1.5 mm amplitude (vertical axis)
8 Hz to 35 Hz: 1 g acceleration (horizontal axis)
8 Hz to 35 Hz: 0.5 g acceleration (vertical axis)
Frequency sweep 1 octave/min
1 cycle in 3 orthogonal axes
Standards IEC 60255-21 and IEC 60068
Vibration
IEC 60255-21-1, Class 2
IEC 60068-2-6
sinusoidal
5 Hz to 8 Hz: ±7.5 mm amplitude;
8 Hz to 150 Hz: 2 g acceleration
Frequency sweep 1 octave/min
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1
IEC 60068-2-27
half-sine shaped
Acceleration 15 g, duration 11 ms,
3 shocks each in both directions of the 3 axes
Continuous shock
IEC 60255-21-2, Class 1
IEC 60068-2-29
half-sine shaped
Acceleration 10 g, duration 16 ms,
1000 shocks each in both directions of the 3 axes
