7XT3400-0*A00/DD Русский
C53000-B119U-C130-1 23
Общая схема
Рисунок 5 Общая схема 7XT3400-0*A00/DD
Корпус для навесного монтажа / Корпус для утопленного монтажа
Выходная полоса
Входная полоса
Делитель напряжения
