Siemens A35 - 2 Required Equipment; 3 Required Software

V1.0 Page 5 of 38 ICM MP CC ST
A35-A36-A40 Company Confidential 09/01
2. Required Equipment for Level 2,5e A35/36/40
Ø GSM-Tester (CMU200 or 4400S incl. Options)
Ø PC-incl. Monitor, Keyboard and Mouse
Ø Bootadapter 2000 (L36880-N9241-A200)
Ø Troubleshooting Frame A35/36 (F30032-P81-A2)
Ø Power Supply
Ø Spectrum Analyser (Advantest 3221)
Ø RF-Probe incl. Power Supply (e.g. from Agilent)
Ø Oscilloscope incl. Probe
Ø RF-Connector (N<>SMA(f))
Ø Power Supply Cables
Ø Dongle (F30032-P28-A1)
Ø BGA Soldering equipment
Reference: Equipment recommendation Level 2,5e
3. Required Software for Level 2,5e A35/36/40
Ø Windows NT Version4
Ø Winsui version1.22 or higher
Ø Winswup
Ø Windows software for GSM-Tester ( Cats or CMU-GO)
Ø Software for 13MHz adjustment
Ø Internet unblocking solution for “Service Mode”
