Page #5 background image
Company Confidential s Com
Copyright 2005© Siemens AG
Page 5 of 53
TD_Repair_L2.5_A70_A75_R1.0.pdf Release 1.0
2 List of available level 2,5e parts A70
(according to Component Matrix V1.03 - check C-market for updates)
Product
RF
Chipset
ID Order Number Description CM
A70 HIT C204 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C230 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C368 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C369 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C370 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C371 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C372 L36377-F6105-K CAPACITOR 1U (Cap-Type6)
A70 HIT C373 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C377 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT C916 L36377-F6225-M CAPACITOR 2U2 (Cap-Type4)
A70 HIT D171 L50610-L6150-D670 IC EGOLDLITE PMB7860
A70 HIT D361 L50645-J4682-Y55 IC ASIC SALZBURG75 TWIGO3+75
A70 HIT D901 L50651-Z2002-A82 IC MODUL PA PF0814 (PA-Type2)
A70 HIT D902 L50645-K280-Y303 IC FEM HITACHI GSM900 1800 1900 (Fem-Type5)
A70 HIT D903 L50620-L6170-D670 IC TRANCEIVER HD155165BP PB Free
A70 HIT N308 L50610-C6153-D670 IC V-REG 2.9V (Vr-Type2) PB Free
A70 HIT R106 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R141 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R201 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R204 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R205 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R221 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R222 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R295 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R371 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R805 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R902 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT R955 L36120-F4223-H RESISTOR TEMP 22K (Res-Type7)
A70 HIT R958 L36852-C-X RESISTOR 0R0 (Res-Type8)
A70 HIT V151 L36840-D5062-D670 DIODE RB751S (Di-Type3)
A70 HIT V211 L36830-C1097-D670 TRANSISTOR FDG313N (Tra-Type1)
A70 HIT V222 L36830-C1112-D670 TRANSISTOR SI1902 (Tra-Type4)
A70 HIT V361 L36830-C1110-D670 TRANSISTOR SI3911 (Tra-Type3)
A70 HIT Z171 L50645-F102-Y40 QUARZ 32,768KHZ (Q-Type4)
A70 HIT Z211 L50640-U6034-D670 FILTER EMI (Fi-Type3) PB Free
A70 HIT Z950 L36145-F260-Y17 QUARZ 26MHZ (Q-Type4)
