Siemens Electromotoric actuators for valves A6V10628469_de--_c
Building Technologies 2018-03-12
Type summary
Product no. Stock no. Stroke
Pos.
force
Operating
voltage
Positioning
signal
Spr. ret.
time
Pos.
time
LED
Manual
adjuster
Extra
functions
SAY31P03
S55150-
A132
15 mm 200 N
AC 230 V 3-position
- 30 s
-
Push and fix
1)
SAY61P03
S55150-
A133
AC/DC 24 V
DC 0…10 V
DC 4…20 mA
0…1000 Ω
Ο
2)
,
3)
SAY81P03
S55150-
A134
3-position
-
1)
1)
Optional accessories: Auxiliary switch ASC10.51
2)
Positioning feedback, forced control, characteristic curve changeover
3)
Optional accessories: Auxiliary switch ASC10.51, sequence control, control action changeover
AZX61.1
Product no.
Auxiliary switch
ASC10.51
Function module
AZX61.1
Stock no. S55845-Z103 S55845-Z107
SAY31P..
Max. 2 Max. 1 AZX61.1
SAY61P..
SAY81P..
Weather shield ASK39.1
Ordering
Product no. Stock no. Description Quantity
SAY81P03 S55150-A134 Actuator 1
ASC10.51 S55845-Z103
Auxiliary switch
1
Actuators, valves and accessories are supplied in individual packs.
Product number /
Stock number
Housing cover Screw (valve stem coupling)
U-bracket
8000060843
Electrical accessories
Mechanical Accessory
Example
Delivery
Spare parts
