Siemens ARCADIS Varic Service Manual

ARCADIS n.a. SP00-000.841.01 Page 8 of 10 Siemens AG
System Manual Rev. 01 08.05 CS PS 24 Medical Solutions
3 - 8 Installing the ON/OFF assembly
Concluding work 3
Closing all covers 3
Close all covers again. Make sure that the protective ground wire connections make good
contact.
Ground wire test 3
Perform the ground wire test according to ARTD-002.731.17....
Also observe the information on the ground wire test in chapter 1 of these instructions.
Document the measuring procedure.
The measured values must be documented and evaluated in the ground wire resistance
protocol.
The ground wire resistance must not exceed 0.2 ohms.
Evaluate the results by comparing the first measured value to the
corresponding values documented during preceding
maintenance procedures or safety checks.
A sudden or unexpected increase of the measured values,
even if the limit value of 0.2 ohms is not exceeded,
indicates errors in the ground wire connections.
(Ground wire or contacts)
NOTE

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
