Chapter 1 – Product Overview
Hardware Outputs
7
Siemens Industry, Inc. Owner's Manual 125-5093
Building Technologies 2015-10-14
Digital
ATTN.UNATTN (through DI 2) Application 6741
Application 6742
OCC.UNOCC (through DI 2) Application 6741
Application 6742
(Optional) High/Low select (through DI 2) Application 6740
OCC Face Velocity Setpoint (through ODP –
optional)
Application 6741
Application 6742
(Optional) Startup Mode (through DI 4) Application 6740
(Optional) Remote Emergency Purge (through
DI 6)
Application 6741
Application 6742
Hardware Outputs
Analog
AO 3 Analog Actuation Application 6742
Operator Display Panel (ODP) Application 6740
Application 6741
Application 6742
AO 2 (flow signal, 1 to 10 Vdc) Application 6740
Application 6741
Application 6742
Digital
Autozero Solenoid in Offboard Air Module (DO
8)
Application 6740
Application 6741
Application 6742
(Optional) Alarm (DO 7) Application 6740
Application 6741
Application 6742
(Optional) OFF Mode (DO 6) Application 6740
Application 6741
Application 6742
HI/LO Indication (DO 5) Application 6740
Exhaust damper (DO 1 and DO 2, Floating
Control Actuation)
Application 6740
Application 6741
Ordering Notes
BACnet Fume Hood Controller - Vertical Sash Configuration with
Damper or Venturi Air Valve, 2 Position CV with Damper
570-00701, 570-
00701PA
