Inmediately after, the Module Line will be connected.
If any of the groups has not been configured correctly or can not communicate with the module line, the
display will show the messages “Group Number” and “Fault”, also an acoustic signal will go off indicating
the error. If none of the groups respond, the module line will be automatically disconnected -OFF position-.
Please inform your installer.
3.1 Led codes in the detectors
Blinking when the detector is in idle mode:
•Operating OK.
Fast Blinking:
•Detector not initialised.
•Detector not recognised by the Module Line.
•The programmed detector number coincides with another detector´s number.
Permanently lit up :
•It indicates that the CO concentration detected is equal to or above 50 ppm -only applicable to CO Detectors-.
•It indicates that the gas concentration detected is equal to or above 20% L.E.L. -only applicable to EXP
Detectors-.
4. USER PROGRAMMING
(Module line in ON MODE)
4.1 Setting the clock
1. Press PROGRAMMING.
“User Program.” is displayed.
2. Press PROGRAMMING to enter.
“Clock” is displayed.
3. Press PROGRAMMING to adjust.
The hour is displayed blinking.
4. Press FORWARD until you reach the right hour.
5. Press ENTER to memorise.
Follow the last 2 steps to adjust the minutes and the date.
4.2 Cyclical ventilation
This menu allows to program an Automatic Ventilation every 1, 3, 6, 12 or 24 hours, without being detected a
ventilation or alarm condition by the detectors. Default programming of cyclical ventilations is “0”.
1. Press PROGRAMMING.
The group number is displayed.
