10 / 38
Siemens Climatix HMI-TM CB1P3917en_redesigned
Smart Infrastructure HMI-TM overview 2023-06-13
①
Key
②
Key
③
Key
④
•••
To indicate there are characters hidden in this line.
1. If the string is longer than the length of the line, “•••”
will be displayed at the end of the line. If this line is
highlighted, it will scroll automatically character by
character.
2. In a line with more than one string, if the end part of
a string is covered by the string of next position, “•••”
will be displayed at the end of the string. When this
line is highlighted, the first string with covered text
will scroll automatically character by character.
The character scrolling function assures that every
character is displayed completely each time.
⑤
► To indicate a sub-menu exists
⑥
Key
⑦
▲
The icon on the right margin is to indicate key UP.
The icon on the upper margin is to indicate there are
other line(s) hidden above the current page.
+
On the value-editing page, the icon “▲” becomes “+” to
indicate that the key is used for value increasing.
⑧
▼
The icon on the right margin is to indicate key DOWN.
The icon on the upper margin is to indicate there are
other line(s) hidden below the current page.
-
On the value-editing page, the icon “▼” becomes “-” to
indicate that the key is used for value decreasing.
⑨
To indicate the HMI-TM does not login with any user
level
To indicate the current user level is End User
To indicate the current user level is Service
To indicate the current user level is OEM Factory
⑩
1/11
To indicate the total number of lines in this page is “11”,
and the 1
st
line is currently being selected
⑪
Title area
The title line, which will never be highlighted, supports all
tokens and has the same characteristics as the lines in
content area.
The target page can be defined by application engineer
on this line. When users press key INFO and the current
user level has the privilege to access to this target page,
it will redirect to this page. Regarding how to program a
title line, refer to Climatix SCOPE online help.
