1.7 Product variants
HMI
-
TM variant
S
p
e
c
i
f
i
c
s
POL871.x1: HMI-TM for magnetic
mounting and mobile operation
> With 4-wire twisted pair spiral cable, with one RJ45 plug
>
Total cable length 2.5 m (1 m flat, 1.5 m expandable spiral cable)
POL871.x2: HMI-TM for mounting in
control panels
> Separate 1.5 m Cat-5 Ethernet cable (8-wire twisted pair) with two RJ45 plugs
>
Two terminals
with screws (for assemblies requiring IP65)
2 Connections
The local connection is a peer-to-peer connection between one HMI-TM and one
Climatix controller.
The maximum distance between HMI-TM and controller is 50 m via shielded
standard 8-wire twisted net cable.
For detail information, refer to Mounting Instruction CB1M3917en.
In case the Climatix controller is connecting to an HMI-TM (POL871) and
downloading the HMI.BIN file, the connection will not start until the downloading
process completes.
Cable for magnetic mounting and mobile
operation POL871.x1
Cable for mounting in control panels
POL871.x2
2.5 m customized cable with 1 RJ45 plug
and 1 slim connector (4-wire twisted pair)
1.5 m Cat-5 Ethernet cable with 2 RJ45
connectors (8-wire twisted pair)
