Siemens Connect Box User Manual

3
Smart Infrastructure A6V13605540_en--_b
Smart Infrastructure 2022-10-14
With the Connect Box on-premise license, data can either be sent to a server by MQTT
(default connection via IP / LAN) or be converted to BACnet IP or Modbus IP. Configuration,
pairing of equipment, and selection of properties are carried out remotely on our web
platform (console of configuration) thanks to a provided 4G SIM card used only for
configuration. Remote management and configuration is offered for the first 3 years.
Alternatively, it can be configured remotely without additional cost using a LAN connection.
Type summary
Type Order number Detail
CWG.BOX-EU S55813-Y100 Connect Box hardware for Europe
CWG.BOX-NA S55813-Y110 Connect Box hardware for North America
CWG.BOX-A S55813-Y120 Connect Box hardware for Asia
Software licenses
To activate the Connect Box hardware, at least one software license is required.
Type Order number Detail
CWG.L1-IOT P55695-L100-A100 1 year cloud license IoT for Connect Box
CWG.L1-S P55695-L100-A110 1 year cloud license Small for Connect Box
CWG.L1-M P55695-L100-A120 1 year cloud license Medium for Connect Box
CWG.L1-L P55695-L100-A130 1 year cloud license Large for Connect Box
CWG.L1-SAT P55695-L100-A140 1 year cloud license Satellite for Connect Box
CWG.L1-ADD2 P55695-L100-A160 1 year 50 data points add-on for IoT/S/M Connect Box
CWG.L1-ADD3 P55695-L100-A170 1 year 1.000 data points add-on for L Connect Box
CWG.L3-IOT P55695-L100-A200 3 years cloud license IoT for Connect Box
CWG.L3-S P55695-L100-A210 3 years cloud license Small for Connect Box
CWG.L3-M P55695-L100-A220 3 years cloud license Medium for Connect Box
CWG.L3-L P55695-L100-A230 3 years cloud license Large for Connect Box
CWG.L3-SAT P55695-L100-A240 3 years cloud license Satellite for Connect Box
CWG.L3-ADD2 P55695-L100-A260 3 years 50 data points add-on for IoT/S/M Connect Box
CWG.L3-ADD3 P55695-L100-A270 3 years 1.000 data points add-on for L Connect Box
CWG.L5-IOT P55695-L100-A300 5 years cloud license IoT for Connect Box
CWG.L5-S P55695-L100-A310 5 years cloud license Small for Connect Box
CWG.L5-M P55695-L100-A320 5 years cloud license Medium for Connect Box
CWG.L5-L P55695-L100-A330 5 years cloud license Large for Connect Box
CWG.L5-SAT P55695-L100-A340 5 years cloud license Satellite for Connect Box
CWG.L5-ADD2 P55695-L100-A360 5 years 50 data points add-on for IoT/S/M Connect Box
CWG.L5-ADD3 P55695-L100-A370 5 years 1.000 data points add-on for L Connect Box
CWG.L6-IOT P55695-L100-A400 Connect Box (on-premise) IoT license
CWG.L6-S P55695-L100-A410 Connect Box (on-premise) Small license
CWG.L6-M P55695-L100-A420 Connect Box (on-premise) Medium license
CWG.L6-L P55695-L100-A430 Connect Box (on-premise) Large license
CWG.L6-XL P55695-L100-A440 Connect Box (on-premise) XLarge license
CWG.L6-R P55695-L100-A450 Connect Box (on-premise) remote configuration renewal for 3 years
Additional required material (not provided)
● Stabilized power supply:
– Input: AC 85-264 V
– Output: DC 24 V ±10%, min. 2 A
The additional material cannot be ordered through Siemens.
