7
Smart Infrastructure A6V13605540_en--_b
Smart Infrastructure 2022-10-14
Technical data
Power supply (not provided)
Input AC 85-264V
Output DC 24V ±10%, min. 2A
Cable between power supply and Connect Box 2 wires (red, black)
22 AWG , minimum section: 0.35 mm
2
Internal protection Protection against overvoltage, undervoltage, and
overcurrent from the power supply with indication by
LED: green LED when the power supply is compatible,
red LED if it is not suitable.
Function data
Hardware information
Processor ARM Cortex A7, 528MHz
Operating system Linux
Storage 512 MB RAM
4 GB Flash
Interfaces
Ethernet interface
Plug 2 x RJ45, shielded
Interface type 10Base-T / 100Base-TX, IEEE 802.3 compatible
Bit rate 10/100Mbps, autosensing
Protocol BACnet/IP on UDP/IP, BACnet/SC on TCP/IP, and
HTTPS on TCP/IP
Cabling (in-house cabling only), cable type 10Mbps: Min. CAT3, shielded cable is recommended
100Mbps: Min. CAT5, shielded cable is recommended
Cable length Max. 100m (330ft)
Modbus RTU interface
Interface type EIA-485, not isolated
Baud rate 300, 600, 1200, 2400, 4800, 9600, 19200, 38400,
57600, 76800, 115200 (depending on the configuration)
Bus termination 120 Ohm to be added on connector by the integrator on
the bus (both ends of the bus)
Internal bus polarization No
Cabling (in-house cabling only)
Cable length
3-wire cable, shielded cable recommended (shield must
be connected to building earth in the mounting panel)
Protection Short-circuit protection with resettable fuse
-7 V to +12 V common-mode
Up to 15 V overvoltage protection
