Siemens Connect Box User Manual

8
Smart Infrastructure A6V13605540_en--_b
Smart Infrastructure 2022-10-14
Cellular interface
Interface type Cellular 2G / 3G / 4G
Supported standards
Frequency band and antenna gain
Maximum radio-frequency power
GSM850 33dBm
EGSM900 33dBm
DCS1800 30dBm
PCS1900 30dBm
GSM850 (8-PSK) 27dBm
EGSM900 (8-PSK) 27dBm
DCS1800 (8-PSK) 26dBm
PCS1900 (8-PSK) 26dBm
WCDMA B1-2-5-8 24dBm
LTE-FDD B1-3-4-5-7-8-12-13-18-19-20-26-38-40-41
23dBm
Rx sensitivity -110dBm
698~960MHz 1.0~5.0dBi
1710~2690MHz -1.0~3.8dBi
Antenna type Omnidirectional rubber antenna with SMA connector
Typical impedance 50 Ohm
KNX interface
Type KNX S and LTE mode
Baud rate: 9600 bauds
Cabling (in-house cabling only) 2-wire cable, 0.75 mm
2
/ AWG20
or 1 mm
2
/ AWG18
With external supply
Internal bus power Sink max 50 mA
USB interface
Plug Type B (USB device)
Data rate (USB 2.0 full speed) 12 Mbps
Protective switch against surges and over current Yes
Galvanic isolation of system neutral ⏊ No
