LoRaWAN interface
Interface type Long range wide area network (LoRaWAN) 1.0
Supported standards
Frequency band and antenna gain
Maximum radio-frequency power
LoRa 868 or 915
From 863 to 870 MHz 3.56dBi or
902 to 928 MHz 4.51 dBi
Tx power up to 27dBm
Rx sensitivity -139dBm@SF12, BW 125 kHz
Asia - AS_923_1
All SF5 to SF12
Uplink: 923.20 MHz, 923.40 MHz, 923.60 MHz, 923.80
MHz, 924.00 MHz, 924.20 MHz, 924.40 MHz, 924.60
MHz
Dowblink: 923.2 MHz
Asia - AS_923_2
All SF5 to SF12
Uplink: 921.40 MHz, 921.60 MHz, 921.80 MHz, 922.00
MHz, 922.20 MHz, 922.40 MHz, 922.60 MHz, 922.80
MHz
Downlink: 921.4 MHz
Asia - AS_923_3
All SF5 to SF12
Uplink: 916.60 MHz, 916.80 MHz, 917.00 MHz, 917.20
MHz, 917.40 MHz, 917.60 MHz, 917.80 MHz, 918.00
MHz
Downlink: 916.6 MHz
Australia - AU_915_928
All SF5 to SF12
Uplink : 916.8 MHz, 917.0 MHz, 917.2 MHz, 917.4
MHz, 917.6 MHz, 917.8 MHz, 918.0 MHz, 918.2 MHz
Downlink: 923.3 MHz
Europe - EU_863_870
All SF5 to SF12
Uplink: 868.10 MHz, 868.30 MHz, 868.50 MHz, 867.10
MHz, 867.30 MHz, 867.50 MHz, 867.70 MHz, 867.90
MHz
Downlink: 869.525 MHz
Europe - EU_433
All SF5 to SF12
Uplink : 433.175 MHz, 433.375 MHz, 433.575 MHz
Downlink : 434.665 MHz
India - IN_865_870
All SF5 to SF12
Uplink: 865.0625 MHz, 865.4025 MHz, 865.985 MHz
Downlink: 866.550 MHz
US - US_902_928
All SF5 to SF12
Uplink (sub-band 2): 903.90 MHz, 904.10 MHz, 904.30
MHz, 904.50 MHz, 904.70 MHz, 904.90 MHz, 905.10
MHz, 905.30 MHz
Downlink: 923.3 MHz
Antenna type Omnidirectional rubber antenna with SMA connector
Typical impedance 50 Ohm
Screw terminals, plug-in
Cu-wire or Cu-strand with wire end sleeve 1 x 0.6mm ∅ to 2.5mm
2
(22 to 14AWG)
or 2 x 0.6mm ∅ to 1.0mm
2
(22 to 18AWG)
Cu-strand without wire end sleeve 1 x 0.6mm ∅ to 2.5mm
2
(22 to 14AWG)
or 2 x 0.6mm ∅ to 1.5mm
2
(22 to 16AWG)
Stripping length 6...7.5mm (0.24...0.29 in)
Screwdriver Slot screws, screwdriver size 1 with shaft ø = 3 mm
Max. tightening torque 0.6 Nm (0.44 lb ft)
