Properties Description Additional information
PROFINET interface (X150 P1R,
X150 P2R, X150 P3)
The interface has three ports. In addition to basic
PROFINET functionality, it also supports PROFINET IO RT
(Real-Time) and IRT (Isochronous Real-Time). The inter
face can be operated isochronously with the clock
pulse system of SINAMICS Integrated and the X142
technology I/Os.
PROFINET interface (X160P1) The interface has one port. In addition to basic
PROFINET functionality, it also supports PROFINET IO RT
(Real-Time).
PROFINET interface
(X130P1)
The interface has one port. It supports basic PROFINET
functionality.
Operation of the CPU as
• IO controller
• I-device
• IO controller:
As an IO controller the CPU controls the connected
IO devices
• I‑device:
As an I-device (intelligent IO device) the CPU is
assigned to a higher-level IO controller and is
thereby used as an intelligent pre-processing unit
of sub-processes
• Section Connecting (Page 43)
• PROFINET function manual
(https://support.industry.
siemens.
com/cs/ww/en/view/49948856
)
PROFIBUS DP
PROFIBUS interface (X126) The interface is used for connecting to a PROFIBUS net
work.
Operation of the CPU as a DP
master
As a DP master, the CPU addresses the connected DP
slaves. The CPU cannot be a DP slave.
Isochronous mode The PROFIBUS interface can be operated isochronously.
However, isochronous coupling with the clock pulse
system of SINAMICS Integrated and the X142 techno
logy I/Os is not possible.
Section Connecting (Page 43)
PROFIBUS function manual
(https://support.industry.siemens.
com/cs/ww/en/view/59193579)
Additional interfaces
USB 3.0 (X125, X135) Non-functional, no connection permitted -
DRIVE-CLiQ interfaces
(X100 to X103)
The SIMATIC Drive Controller has four DRIVE-CLiQ inter
faces. For each DRIVE-CLiQ interface, you have
24V/450mA available for connecting encoders and
measuring systems.
Section Connecting (Page 43)
Integrated inputs and outputs
12 DI (X122, X132) The digital inputs are assigned to SINAMICS Integrated
. You use the digital inputs, for example, for the control
of Safety Integrated basic functions via a terminal.
Alternatively, you assign the digital inputs to the CPU,
by means of configuration with telegram 39x.
8 DI/DQ (X122, X132) The bidirectional digital inputs/outputs are assigned to
SINAMICS Integrated . You use the digital inputs/out
puts, for example, as measuring inputs via a PROFIdrive
telegram.
Alternatively, you assign the digital inputs/outputs to
the CPU, by means of configuration with telegram 39x.
Section Connecting (Page 43)
25
Product overview
3.4 Hardware properties
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
