Technical data of CPU 31xC
6.6 Technical data of the integrated I/O
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
6-53
Technical data
Voltage output
• Short-circuit protection
Yes
• Short-circuit current
Typically 55 mA
Current output
• No-load voltage
Typically 17 V
Destruction limit for externally applied voltages/currents
• Voltage measured between the outputs and M
ANA
Max. 16 V
• Current
Max. 50 mA;
Connection of actuators
• For voltage outputs
– wire connection
– wire connection (test lead)
Possible, without compensation of
cable resistance
Not possible
• For current outputs
– wire connection
Possible

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
