Siemens CPU 315-2 DP User Manual

Communication
3.3 S7 connections
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
3-27
3.2.10.5 SNMP communication service
Availability
The SNMP communication service is available for CPUs with integrated PROFINET
interface and Firmware 2.3.0 or higher.
Properties
SNMP (Simple Network Management Protocol)) is a standard protocol for TCP/IP networks.
Reference
For further information on the SNMP communication service and diagnostics with SNMP,
refer to the
PROFINET System Description.
3.3 3.3 S7 connections
3.3.1 S7 connection as communication path
An S7 connection is established when S7 modules communicate with one another. This S7
connection is the communication path.
Note
Global data communication, point-to-point connection, no S7 connections are required for
communication via PROFIBUS DP, PROFINET CBA, PROFINET IO, TCP/IP, ISO on TCP,
UDP and SNMP
Every communication link requires S7 connection resources on the CPU for the entire
duration of this connection.
Thus, every S7 CPU provides a specific number of S7 connection resources. These are
used by various communication services (PG/OP communication, S7 communication or S7
basic communication).

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
