Abbreviations and Mnemonics
10
S7-400 Instruction List
A5E00267845-01
Abbreviations and Mnemonics
The following abbreviations and mnemonics are used in the Instruction List:
Abbrev. Description Example
k8 8-bit constant
0 to 255
32
k16 16-bit constant
256 to 32 767
28 131
k32 32-bit constant
32 768 to 999 999 999
127 624
i8 8-bit integer
-128 to +127
-113
i16 16-bit integer
-32768 to +32767
+6523
i32 32-bit integer
-2 147 483 648 to +2 147 483 647
-2 222 222
m Pointer constant P#240.3
n Binary constant 1001 1100
p Hexadecimal constant EA12
Label Symbolic jump address (max. 4 characters) DESTINATION
a Byte address
