Logic Instructions with Timers and Counters
31
S7-400 Instruction List
A5E00267845-01
Logic Instructions with Timers and Counters
Examining the status of the addressed timer/counter and gating the result with the RLO according to the appropriate logic function.
In-
struc-
Length
in
Words
Execution Time in s
In-
struc-
tion
Address ID Description
in
Words
Execution Time in s
CPU 412 CPU 414 CPU 416 CPU 417
A/AN
Tf
T [e]
Cf
C [e]
AND/AND NOT
Timer
Timer, memory-indirect addressing
Counter
Counter, memory-indirect addressing
1*/2
2
1*/2
2
0.1/0.125
0.1+
0.1/0.125
0.1+
0.06/0.075
0.06+
0.06/0.075
0.06+
0.04/0.05
0.04+
0.04/0.05
0.04+
0.03/0.042
0.03+
0.03/0.042
0.03+
Timerpara.
Counter para.
Timer/counter (addressing via param-
eter)
2 0.1+
0.1+
0.06+
0.06+
0.04+
0.04+
0.03+
0.03+
Status word for: A, AN BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – – Yes – Yes Yes
Instruction affects: – – – – – Yes Yes Yes 1
+ Plus time required for loading the address of the instruction (see page 20)
*
)
With direct instruction addressing ;Address area 0 to 255
