Bit Logic Instructions with Parenthetical Expressions
29
S7-400 Instruction List
A5E00267845-01
Bit Logic Instructions with Parenthetical Expressions, continued
In-
struc-
tion
Address
ID
Description
Length
in
Execution Time in s
struc-
tion
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
) Right parenthesis, removing an
entry from the nesting stack.
1 0.1 0.06 0.04 0.03
Statusword for: ) BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – – – – Yes –
Instruction affects: – – – – – Yes 1 Yes 1
