System Functions
120
S7-400 Instruction List
A5E00267845-01
Execution Time in s
SFC
No.
SFC Name Function
CPU
412
CPU
414
CPU
416
CPU
417
CPU
414-4H
417-4H
(solo)
CPU
414-4H
417-4H
(redun-
dant)
51 RDSYSST “DP master system information” partial list
All known DP master systems of the CPU
(0090)
258 158 105 92 xx - xx xx - xx
A DP master system (0190) 134 80 53 47 xx - xx xx - xx
Header information (0F90) 112 67 44 39 xx - xx xx - xx
51 RDSYSST “Module status information” partial list
Display status information of all inserted
modules (n=number of DR) (0091)
561 +
n * 22
329 +
n * 19
218 +
n * 16
180 +
n * 14
-- --
Display status information of all modules
/racks with incorrect type indentification
(0191)
546 +
n * 70
381 +
n * 60
230 +
n * 40
220+
n * 35
-- --
All faulty modules (0291) 515 +
n * 99
371 +
n * 22
246 +
n * 18
213 +
n * 18
-- --
All unavailable modules (0391) 517 +
n * 69
376 +
n * 60
249 +
n * 40
216 +
n * 35
-- --
All submodules of the host module (0591) 169 102 67 59 -- --
51 RDSYSST Display the status information of all
submodules of the host module in the
specified rack (0991)
299 +
n * 12
179 +
n * 7
118 +
n * 5
103 +
n * 4
-- --
Central
a module with logical basic address
(0C91)
182 118 78 69 xx xx
