Word Logic Instructions with the Contents of Accumulator 1
34
S7-400 Instruction List
A5E00267845-01
Word Logic Instructions with the Contents of Accumulator 1, continued
Instruc-
tion
Address
ID
Description
Length
in
Execution Time in s
Instruc-
tion
Address
ID
Description
Length
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
AD AND ACCU2 1 0.1 0.6 0.04 0.3
AD DW#16#p AND 32-bit constant 3 0.185 0.112 0.075 0.062
OD OR ACCU2 1 0.1 0.06 0.04 0.3
OD DW#16#p OR 32-bit constant 3 0.185 0.112 0.075 0.062
XOD EXCLUSIVE OR ACCU2 1 0.1 0.06 0.04 0.03
XOD DW#16#p EXCLUSIVE OR 32-bit constant 3 0.185 0.112 0.075 0.062
Status word for: UD, OD, XOD BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates:
Instruction affects: Yes 0 0
