Integer Math (16 Bits)
62
S7-400 Instruction List
A5E00267845-01
Instruc-
Address
Description
Length
in
Execution Time in s
Instruc-
tion
Address
ID
Description
Length
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
*
I Multiply 1 integer by another (16 bits)
(ACCU1)=(ACCU2-L)
*
(ACCU1-L)
1 0.1 0.06 0.04 0.03
/I Divide 1 integer by another (16 bits)
(ACCU1-L)=(ACCU2-L):(ACCU1-L)
The remainder is in ACCU1-H
1 0.1 0.24 0.16 0.12
Status word for:
*
I, /I BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – – – – – –
Instruction affects: – Yes Yes Yes Yes – – – –
