Siemens CPU 414-2 - D; MOD

Integer Math (32 Bits)
64
S7-400 Instruction List
A5E00267845-01
Instruc-
Address
Description
Length
in
Execution Time in s
Instruc-
tion
Address
ID
Description
Length
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
/D Divide 2 integer by another (32 bits)
(ACCU1)=(ACCU2):(ACCU1)
1 0.6 0.36 0.24 0.18
MOD Divide 2 integer by another (32 bits) and
load the remainder into ACCU1:
(ACCU1)=remainder of
[(ACCU2):(ACCU1)]
1 0.6 0.36 0.24 0.18
Status word for: /D, MOD BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – – – – – –
Instruction affects: – Yes Yes Yes Yes – – – –
