Siemens CPU 414-2 - JO; JOS

Jump Instructions
93
S7-400 Instruction List
A5E00267845-01
Jump Instructions, continued
Instruc-
tion
Address
ID
Description
Length
in
Execution Time in s
Instruc-
tion
Address
ID
Description
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
JO LABEL Jump on stored overflow
(OV = “1”)
2 0.6; 0.125
2)
0.36; 0.075
2)
0.24; 0.05
2)
0.21; 0.042
2)
Status word for: JO BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – Yes – – – – –
Instruction affects: – – – – – – – – –
JOS LABEL Jump on stored overflow
(OS = “1”)
2 0.6/0.125
2)
0.36/0.075
2)
0.24/0.05
2)
0.21/0.042
2)
Status word for: JOS BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – Yes – – – –
Instruction affects: – – – – 0 – – – –
2)
If jump is not executed
