Jump Instructions
96
S7-400 Instruction List
A5E00267845-01
Jump Instructions, continued
Instruc-
tion
Address
ID
Description
Length
in
Execution Time in s
Instruc-
tion
Address
ID
Description
in
Words
CPU 412 CPU 414 CPU 416 CPU 417
JL LABEL Jump distributor
This instruction is followed by a list
of jump instructions.
The address identifier is a jump label
to subsequent instructions in this list.
ACCU1-LL contains the number of
the jump instruction to be executed
(max. 254). The number of the first
jump instruction is 0.
2 0.7 0.42 0.28 0.24
LOOP LABEL Decrement ACCU1-L and jump if
ACCU1-L 0 0
(loop programming)
2 0.6/0.125
1)
0.36/0.075
1)
0.24/0.05
1)
0.21/0.042
1)
Status word for: JL, LOOP BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – – – – – –
Instruction affects: – – – – – – – – –
1)
If jump is not executed
