en Getting to know your appliance
10
* Getting to know your
appliance
Get t i ng to know your appl i ance
This section provides an overview of
the scope of delivery, the assembly and
the components of your appliance. It
also introduces you to the different
controls.
Note: Depending on the appliance
model, individual details and colours
may differ.
The operating instructions refer to two
product variants:
■ Appliance with one bean container
■ Appliance with two bean containers
How to use these instructions:
The cover pages of the operating
instructions can be folded out towards
the front. The illustrations are identified
using numbers that are referred to in the
operating instructions.
Example: ~ Fig. !
Included in delivery
~ Fig. !
The item marked with ** is only supplied
with certain appliances.
Assembly and components
~ Fig. "
Depending on the model:
Items marked with * are only present in
the appliance with two bean containers.
# Fully automatic coffee machine
+ Milk container (container, lid,
riser, connection hose)
3 Operating instructions
;** Water filter
C Measuring spoon
K Water hardness testing strip
( Display
0 Control panel
8 Rotary selector/start- stop
(rotate and press to navigate)
@ Outlet system (coffee, milk, hot
water), height adjustable
H Milk container (container, lid, riser,
connection hose)
P Drip tray (coffee grounds
container, drip plate)
X Brewing chamber cover
` Water tank
h Rating plate
)" Recessed grip on water tank
)* Cup warmer
)2 Cup warmer LED display
): Grind compartment (ground
coffee/cleaning tablet)
)B Bean container
)J Rotary selector for grinding level
setting
)R Aroma lid
)Z* Aroma lid
)b* Bean container
)j* Rotary selector for grinding level
setting
1"* Bean container selector buttons,
illuminated
