Siemens FDA241 Series User Manual

3
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
● Mining industry
● Subway stations
● Agricultural operations
● All other applications with visible dust load
Functions
Indication
The display contains clear, comprehensible bar graphs for smoke and airflow, as well as an
alarm indicator, an error indicator, and a dust indicator (FDA241).
When the housing cover is open, the operator has access to the 'Reset', 'Normalize Smoke',
and 'Normalize Flow' functions, as well as the mini USB connector.
Fig.1: Front indicatorFDA241
Fig.2: Front indicatorFDA221
Legend for the response indicators
Operation Flow warnings Smoke alarm Info alarm

Siemens FDA241 Series Specifications

General

Brand	Siemens
Model	FDA241 Series
Category	Smoke Alarm
Language	English
