Siemens Flowrite 599 Series User Manual

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 15
Parts List
Table 12. Parts List for 2-Way Bronze Valves.
See Figure 8 and Figure 8.
Item
Part Name
Part Number
Quantity
Material
1
Packing Cartridge
Assembly
—
1
—
2
Gasket
—
1
Copper
3
Normally Open
3/4-inch to 2-inch Bonnet
—
1
Brass
4
Stem and Plug Assembly
—
1
Bronze or
Stainless
Steel
5
Valve Body
—
1
Bronze
6
O-ring
1
EPDM
7
Normally closed Cap
—
1
Brass
—
Packing Kit
Normal Duty Service
Steam Service
599-03390
599-03391
—
Items 1 and 2
—
Rebuild/Repack Kit
Normally Closed
See Table 14
and Table 15
—
Items 1, 2, 4,
and 6
—
Rebuild/Repack Kit
Normally Open
See Table 14
and Table 15
—
Items 1, 2, 4,
and 6
Valve Assembly
Weight
Table 13. Weight in Pounds (Kilograms).
Valve Size
Normally Closed
Normally Open
.50 (15)
3 (1.4)
3 (1.4)
.75 (20)
4 (1.8)
4 (1.8)
1.0 (25)
5 (2.3)
5 (2.3)
1.25 (32)
7 (3.2)
7 (3.2)
1.50 (40)
8 (3.6)
9 (4.1)
2.0 (50
16 (7.3)
13 (5.9)
