Siemens IPC427 - English

Table of Contents
Specifications on page 3 Installation on page 7
General information on page 4 Maintenance on page 13
Legal Information
Manufacturer: Siemens AG
Distributor: Hach Lange GmbH
The translation of the manual is approved by the manufacturer.
Specifications
Specifications are subject to change without notice.
Note: Possible pixel errors in the TFT display are usual and do not show a defective instrument or display.
Note: Small malfunctions in the touchscreen sensor are usual and do not show a defective touchscreen or display.
Specification IPC427 IPC477 15" IPC477 19"
Processor Intel
®
Core
™
i3-6102E
Processor (3M Cache,
1.9 GHz)
Intel
®
Core
™
i3-6102E Processor (3M Cache, 1.9 GHz)
Flash memory Changeable mass storage CFAST 16 GB.
Interfaces Ethernet 3 x RJ45 (10/100/1000 Mbit/s), 4 × USB 3.0, 2 x DisplayPort, 2x RS232/485
Diagnostic LEDs PC ON/WD, RUN/STOP /
L1, ERROR / L2, MAINT /
L3
— —
Display — 1366 x 768 pixels 1366 x 768 pixels
Clock Internal clock with battery backup for time and date (battery replaceable)
Operating system Microsoft Windows
®
Embedded Standard 7 P
Power supply 24 VDC (–15%/+20%) 24 VDC (–15%/+20%)
Power consumption 24 W without USB devices
(including system
interfaces)
70 W (approximately) 78 W (approximately)
Dimensions (W x H x D)
(not cut out dimension)
262 x 133 x 55.5 /
64.5 mm (10.31 x 5.23 x
2.18 / 2.54 in.)
398 x 257 x 84.9mm
(15.67 x 10.11 x 3.34 in.)
464 x 294x 84.9 mm
(18.26 x 11.57 x 3.34 in.)
Weight 2.2 kg (4.85 lb) 5.2 kg (11.46 lb) 6.7 kg (14.77 lb)
Operating temperature 0 to 50°C (32 °F to 122 °F)
horizontal mounted with
CFast
0 to 50 °C (32 to 122 °F)
vertical mounted with
CFast
0 to 45 °C (32 to 113 °F)
vertical mounted with
CFast
Storage temperature –40 to 70 °C (–40 to
158 °F)
–20 to 60 °C (–4 to 140 °F)
Relative humidity Storage/transport between 5 to 95% non-condensing at 25 ° C (77 °F)
Vibration/shock
resistant
According to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission According to EN 61000-6-2/EN 61000-6-4
Protection class IP20 Front side IP65, rear side IP20
Certification CE marked
English 3
