167
LOGO! Manual
A5E00067781 01
You can also generate a message via output Q4:
Q3
Fault
Q4
Message
The relay contacts of output Q4 are always closed when
the system is running. Relay Q4 does not release unless
there is a power failure or a fault in the system. This con-
tact can be used for teleindication, for example.
Applications

Siemens LOGO! 230RC Specifications

General

Inputs	8 digital inputs
Outputs	4 relay outputs
Mounting Type	DIN rail
Protection Type	IP20
Dimensions	90 x 72 x 55 mm
Output Current	10 A
Operating Temperature	0°C to 55°C
Power Supply	115/230V AC
Storage Temperature	-40°C to +70°C
