6/28
Building Technologies Division CC1N7785en
20.11.2017
Certified with plug-in base and flame detector:
Type reference
LOK16.140... --- --- ---
LOK16.250... --- --- ---
LOK16.650... --- --- ---
LGK16.122... --- ---
LGK16.133A17 --- --- --- ---
LGK16.133A27 --- ---
LGK16.322... --- ---
LGK16.333... --- ---
LGK16.335... --- ---
LGK16.622... --- ---
LGK16.635... --- ---
Service notes
The KF8832 flame detector current measuring device must not be used in continuous
operation.
Life cycle
Burner controls has a designed lifetime* of 250,000 burner startup cycles which, under
normal operating conditions in heating mode, correspond to approx. 10 years of usage
(starting from the production date given on the type field).
This lifetime is based on the endurance tests specified in standard EN 298.
A summary of the conditions has been published by the European Control
Manufacturers Association (Afecor - www.afecor.org).
The designed lifetime is based on use of the burner controls according to the
manufacturer’s Data Sheet. After reaching the designed lifetime in terms of the number
of burner startup cycles, or the respective time of usage, the burner control is to be
replaced by authorized personnel.
* The designed lifetime is not the warranty time specified in the Terms of Delivery
Disposal notes
The unit contains electrical and electronic components and must not be disposed of
together with household waste.
Local and currently valid legislation must be observed.
Mechanical design
Plug-in design
Exchangeable unit fuse (including spare fuse)
Made of impact-proof and heat-resistant black plastic
Lockout reset button with viewing window; located behind it are:
- The lockout warning lamp
- The lockout indicator
- coupled to the spindle of the sequence switch
- visible in the transparent lockout reset button
- uses easy-to-remember symbols to indicate the type of fault and the point in
time lockout occurred
LGK16.../LOK16...
Housing
