EPAC300-M50 SERIES USER’S MANUAL
AUGUST 2005 PAGE 6 OF 46
SECTION 2
EPAC300-M50 SERIES CONTROLLER OVERVIEW
The EPAC300-M50 Series Controller Unit (Figure 1) is an advanced rugged traffic
signal controller unit configurable for traffic management and communications
applications. It meets the latest NEMA specification, which is TS2-2003.
Figure 1: EPAC300-M50 Series Controller
Exceeds the latest NEMA TS2-2003 specifications
Flexible, Modular Design to Meet Specific User Needs
Easy System Upgrades using expansion slots
Standard ATC Modem Option
Compact EIA-3U size (7 inches high)
Rugged, polycarbonate case, same as used in traffic signal housings
Built-in carrying handle
Powerful 32-bit processor
M51 NEMA TS-2, Type 1 Version (serial connection to BIU)
M52 NEMA TS-2, Type 2 Version (parallel connection via NEMA A, B, C)
Built-in 10 Base-T Ethernet with RJ-45 connector and IP address
Built-in infrared wireless port for Personal Data Device (PDA), or Laptop PC
FLASH drive for software & data files, eliminates need to replace PROMs
Removable Front Panel with stowed extension cable, (may delete to save cost)
No batteries, motors, fans or other devices that wear out or require service
Optional internal FSK modem
NTCIP and ECOM (ANSI X 3.28) communications
