1.4.11 AT^SSTGI Remote-SAT Get Information – Get Inkey (34)
Write command
AT^SSTGI=34
This command is to be used upon receiving an unsolicited result code
^SSTN:34.
The TA is asked to prompt the user for an input, which is a single character.
Help can be requested by the user, if available.
Text and an Icon Identifier can be passed to the TA to display to the user.
Response
^SSTGI: <cmdType>, <commandDetails>, <text>, <iconQualifier>, <iconId>
<CR> <LF>
Parameters
<cmdType> 34 – Proactive command ID, see Table 1
<commandDetails> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = digits (0-9, *, # and +) only
1 = alphabet set;
bit 2: 0 = SMS default alphabet (GSM character set)
1 = UCS2 alphabet
bit 3: 0 = character sets defined by bit 1 and bit 2 are
enabled
1 = character sets defined by bit 1 and bit 2 are
disabled and the "Yes/No" response is
requested
bits 4-7: = RFU
bit 8: 0 = no help information available
1 = help information available
<text> String as prompt for text.
<iconQualifier> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = icon is self explanatory and replaces text
1 = icon is not self-explanatory and shall be
displayed with the text
Determined value only if associated icon id is
not 0 (an icon exists).
bits 2-8: = RFU
<iconId> 0-255, 0: no icon
Reference
Siemens
Note
