Remote-SAT User's Guide
P R E L I M I N A R Y
MC35_SAT_01_V01.01a - Preliminary Page 36 of 64 15.11.2001
not 0 (an icon exists).
bits 2-8: = RFU
<titleIconQualifier> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = icon is self explanatory and replaces text
1 = icon is not self-explanatory and shall be
displayed with the text
Determined value only if associated icon id is
not 0 (an icon exists).
bits 2-8: = RFU
<titleIconId> 0-255, 0: no icon
<itemId> item identifier (1 – <numOfItems>)
<itemText> Title of item
<nextActionId> The next proactive command type to be issued upon
execution of the menu item. See Table 1.
0: No Next Action information available.
<iconId> 0-255, 0: no icon
Reference
Siemens
Note
