SINUMERIK 840D
HW PCU
with HMI-Advanced
6.4.33 7.6.2
PCU 50.1 NT X
PCU 50.2 NT X
PCU 50.3 XP SP3 X
PCU 50.5 XP SP3 X
Firewall settings
To allow an error-free connection between the SINUMERIK Integrate server, the NX CAM
server and the SINUMERIK controllers, the following settings must be made:
● Port 8090 for unencrypted connection (HTTP)
● Port 443 for encrypted connection (HTTPS)
For installation on the following server system:
● Configuring the SQL Server 2012 with remote database
● Configuring the SQL Server 2016 with remote database
Make the following settings for the servers with a remote database:
● TCP 1433, UDP 1434.
SQL Server 2012 with remote database: SQL Server 2012 (Page 33)
SQL Server 2016 with remote database: SQL Server 2016 (Page 50)
You need the following ports for the license model of the Windows Server:
● 28000, 28001
Additional information is provided in the following chapter: Set license server (Page 73).
Introduction
2.2 System prerequisites
Manage MyResources, Optimize MyProgramming /NX-Cam Editor
20 Installation Manual, 12/2019, A5E44672080B AE
