EM
13
EXPERT MODE - IMPORTANT PARAMETERS..............
Parameter Function Range
(Default)
Selection control
function, DIN1
(terminal 5), fixed
frequency 5.
(P046)**
0-24
[01]
Selection control
function, DIN2
(terminal 6), fixed
frequency 4.
(P044)**
0-24
[10]
Selection control
function, DIN3
(terminal 7), fixed
frequency 3.
(P043)**
0-24
[6]
Selection control
function, DIN4
(terminal 8), fixed
frequency 2.
(P042)**
0-24
[6]
Selection control
function, DIN5
(terminal 16), fixed
frequency 1.
(P041)**
0-24
[6]
Selection control
function, DIN6
(terminal 17), fixed
frequency 6.
(P047)**
0-24
[6]
** Fixed frequency enabled when P051 to
P055 and P356 is set to 6 or 18. P006
should then be set to 2
Description/Notes
Value Function of P051
to P055 and
P356
Function,
low state
(0 V)
Function,
high state
(>10V)
0 Input disabled - -
1 ON right Off On right
4 OFF2 OFF2 On
5 OFF3 OFF3 On
6 Fixed frequencies 1-
6
Off On
9 Start / stop
command selection
from keypad OR
digital terminals
(for USS
communications
operation P910 = 1
or 3)
Local
keypad start
/ stop
Digital
terminal start
/ stop (or
USS
communi-
cation
control)
10 Fault reset Off Reset on
rising edge
11 Increase frequency* Off Increase
12 Decrease frequency* Off Decrease
13 Switch between
analog input
frequency setting
and digital/keypad
frequency setting
Analog
setpoint
Keypad /
Digital
setpoint
14 Disable ability to
change parameters
P’ enabled P’ disabled
18 Fixed frequencies 1-
6, but input high will
also request RUN
when P007 = 0 See
P040 to P047
Off On
19 External trip Off On
22 Download parameter
set 0 from OPe***
Off Download
23 Download parameter
set 1 from OPe***
Off Download
24 Switch analog
setpoint
Analog
input 1
active
Analog input
2 active
* Only effective when P007 = 0.
*** The motor must be stopped before
downloading begins
Downloading takes approx. 30 seconds
