EXPERT MODE - IMPORTANT PARAMETERS ..............
Parameter Function Range
(Default)
Description/Notes
Selection relay
output RL1
0-13
[6]
Sets the relay function, output RL1
(terminals 18,19 and 20)
Selection relay
output RL2
0-13
[1]
Sets the relay function, output RL2
(terminals 21 and 22)
Value Relay function Active
3
0 No function assigned
(relay not active)
Low
1 Inverter is running High
2 Inverter frequency 0.0 Hz Low
5 Inverter frequency less than
or equal to minimum
frequency
Low
6 Fault indication
1
Low
7 Inverter frequency greater
than or equal to setpoint
High
9 Output current greater than
or equal to P065
High
12 PID closed loop motor LOW
speed limit
High
13 PID closed loop motor
HIGH speed limit
High
1
Inverter switches off (see parameter P930
and P140).
3
‘Active low’ = relay OFF/de-energised or
‘Active high’ = relay ON/energised.
DC injection
braking (%)
0-200
[0]
Range is
variant
dependent
This rapidly stops the motor by applying a DC braking
current and holds the shaft stationary until the end of
the braking period.
Additional heat is generated within the motor.
Braking is effective for a period of time set by P003.
The DC brake can be activated using DIN 1 to DIN 6
(see P051 to P055 and P356).
WARNING: Frequent use of long periods of DC
injection braking can cause the motor to overheat.
If DC injection braking is enabled via a digital input
then DC current is applied for as long as the digital
input is high. This causes heating of the motor.
