Siemens Building Technologies
Fire Safety
P/N 315-048692-23
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SIEMENS BUILDING TECHNOLOGIES
TBL BELL #1 (IAC 1) (main)
TBL INPUT LOOP 2, DEVICE #1
TBL INPUT LOOP 2, DEVICE #4
TBL INPUT LOOP 2, DEVICE #5
TBL INPUT LOOP 2, DEVICE #6
TBL INPUT LOOP 2, DEVICE #7
TBL INPUT LOOP 2, DEVICE #8
TBL INPUT LOOP 2, DEVICE #2
IN
IN
IN
IN
IN
IN ACK
OUT ACK
IN
Example shown is Canadian Display
12:22:22 October 22, 02
ALR=000, SUP=000, TBL=017, SEC=001
TBL BELL #1 (IAC 1) (main)
IN
2-001 Audible Loop
007 Signal Circuit Loop Open
21:22:22 Oct 21, 01
40 Characters
Highlight
Custom
Message
ACK
Status
Highest Priority
Unacknowledged
Event
System Status
Line
Current
Time/Date
Device Type
TBL Type
Event
Time/Date
System
Message
Queue
Event #
Event
Type
Event
Address
(007 / 018)
Event #
Total # of Events
Figure 3
MXL Multi-Line Display in Active Mode
As an example, when a trouble event is annunciated the System places the event on
the display according to its priority or queue (Alarm, Supervisory, Trouble, then
Security) in the format: [Event Type] [Custom Message] [IN/OUT] [ACK STATUS or
BLANK]. The system status in line 10 is also updated to reflect the newest event.
ACK appears in the display if the event has been acknowledged; otherwise, the field
is blank. IN is displayed when an event occurs; OUT is displayed when a normal
state is restored.
To view information about a previous event, press the UP (
) or DOWN ( ) keys
located next to the MORE INFO key to scroll to the desired event and highlight it,
then press the MORE INFO key. Lines 13, 14 and 15 will display the event informa-
tion in the following format:
[event address] [device type]
[event number in queue] [event type]
[event time/date] [event number in all queues] [total number of events]
