SIEMENS BUILDING TECHNOLOGIES
ALM CUSTOM MESSAGE
ALM CUSTOM MESSAGE
IN
IN
Example shown is Canadian Display
12:01:01 Dec 31, 02
ALR=002, SUP=000, TBL=000, SEC=000
ALM CUSTOM MESSAGE
IN
40 Characters
ACK
1-001 ID-60I Ionization Detector
002
11:59:59 Dec 31, 02
(002 / 002)
Figure 5
ALARM Event Screen With More Info Key Pressed
In addition, the System responds to alarms with programmed output functions such
as other audible signals.
In Figure 5, 1-001 represents the address of the device reporting the alarm. On the
display, not all leading zeros are shown. If your System includes a printer, note that
the leading zeros are not shown. 002 on Line 14 in the More Info area (Lines 13-15)
tells you that this is the second (and the most recent) of two alarms received. The
status information shown in Line 10 reports the total number of alarms, supervisories,
troubles, and security conditions.
