Siemens NIC-C User Manual

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-136
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7
DO NOT USE
DO NOT USE
DO NOT USE DO NOT USE
ONE SLOT OF CC-5
FIRST NIC-C
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7
DO NOT USE
DO NOT USE
DO NOT USE
PAIR A
SUPERVISED
POWER LIMITED
ONE SLOT OF CC-5
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7
DO NOT USE
DO NOT USE
DO NOT USE
ONE SLOT OF CC-5
LAST NIC-C
Figure 4
NIC-C Class-B/Style 4 (ULC DCLB) Network Wiring
NOTES:
1. No EOLR required.
2. 18 AWG min., 12 AWG max.
3. 2000 feet (33.8 ohms) max.
per pair between CC-5s/CC-2s.
Unshielded twisted pair
.25μF max. line to line
Shielded twisted pair
.15μF max. line to line
.2μF max. line to shield
4. Terminate shields at one end
only.
5. Power limited to NFPA 70
per NEC 760.
6 CC-5 terminals 9 - 14 are not
connected and can be used
to tie shields together.
7. Positive or negative ground
fault detected at <10K ohms
on pins 1 - 4.
Figure 5
NIC-C Class-X/Style 7 (ULC DCLC) Network Wiring
NOTES:
1. No EOLR required.
2. 18 AWG min., 12 AWG max.
3. 2000 (33.8 ohms) feet max.
per pair between CC-5s/CC-2s.
Unshielded twisted pair
.25μF max. line to line
Shielded twisted pair
.15μF max. line to line
.2μF max. line to shield
4. Terminate shields at one end
only.
5. Power limited to NFPA 70
per NEC 760.
6. CC-5 terminals 9 - 14 are not
connected and can be used
to tie shields together.
7. Positive or negative ground
fault detected at <10K ohms
on pins 1 - 8.
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7
DO NOT USE
DO NOT USE
DO NOT USE DO NOT USE DO NOT USEDO NOT USE
ONE SLOT OF CC-5
FIRST NIC-C
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7
DO NOT USE
DO NOT USE
PAIR A
SUPERVISED
POWER LIMITED
PAIR B
SUPERVISED
POWER LIMITED
ONE SLOT OF CC-5
12345678
910111213141516
17 18 19 20 21 22 23 24
SEE NOTE 7
DO NOT USE
DO NOT USE
ONE SLOT OF CC-5
LAST NIC-C
