Siemens NIC-C User Manual

Siemens Industry, Inc.
Building Technologies Division
P/N 315-033240-137
Figure 6 NCC-2F-HNET-VNT Class-B/Style 4 Wiring
PSC-12
RESET POWER MODULE FAIL H - NET FAIL GND FAULT 24V 12 FAIL 24V 4A FAIL CAN FAIL
TB3
+ -
P4
TB1
P5
TB2
+
+
_
_
H
N
GND
P9
P12
TB4
BATTERY
OFF
O
—
ON
ONES TENS HUNDREDS
HNET
(ONE SLOT
OF
CC-5/CC-2)
LAST
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
(ONE SLOT
OF
CC-5/CC-2)
FIRST
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
(ONE SLOT
OF
CC-5/CC-2)
NIC-C
P3
17 18 19 20 21 22 23 24
12345678
910111213141516
NCC-2F
2
34
*
1
PAIR A SUPERVISED POWER LIMITED
* EOLR 120 OHMS,
1/2W, 5% P/N 140-820350
* EOLR 120 OHMS, 1/2W, 5%
P/N 140-820350
5
TB1
60-PIN RIBBON CABLE FROM PSC-12
CC-2
CC-2
CC-2
60-PIN
RIBBON
CABLE
I I
C
60-PIN
RIBBON
CABLE
I I
C
*
DO NOT USE
DO NOT USE
DO NOT USE
DO NOT
USE
SEE NOTE 6
DO NOT
USE
SEE NOTE 6
DO NOT
USE
SEE NOTE 6
DO NOT USE
DO NOT USE
DO NOT USE
*
NOTES: 1. EOLR required. 2. 18 AWG min., 12 AWG max. 3. 2000 feet (33.8 ohms) max. per pair between CC-5s/CC-2s.
Unshielded twisted pair .25μF max. line to line Shielded twisted pair .15μF max. line to line .2μF max. line to shield
4. Terminate shields at one end only. 5. Power limited to NFPA 70 per NEC 760. 6 CC-5/CC-2 terminals 9 - 14 are not connected and can be used to tie shields
together.
7. Positive or negative ground fault detected at
<10K ohms on pins 1 - 4.
8. Remove jumper P2 from all NIC-Cs in this wiring configuration except on the
NIC-C that is connected to the NCC-2F card.
