Manual OP5, OP15
( ) J31069-D0840-U001-A2-7618
The different editions of the equipment manual refer to the following Pro-
Tool/Lite versions or OP firmware versions.
Edition Remarks ProTool/Lite-
Version
OP-Firmware
06/95 First edition of the manual Up to V 1.01 OP5: From V 1.20
OP15: From V 2.20
01/96 Expansion of the manual
to include recipe and
scheduler functions
From V 2.0 OP5: From V 1.30
OP15: From V 2.30
For technical questions, get in touch with your local Siemens representative.
You will find the addresses in appendix F of this manual, in our catalogs and
under Compuserve (go autforum) to mention a few examples. In addition,
our hotline is ready to help you (telephone +49 (911) 895–7000,
fax +49 (911) 895–7001).
AS511 Protocol of the PU interface to the SIMATIC S5
ASIC Application-specific integrated circuit
CPU Central processing unit
EM Equipment manual (German abbreviation: GHB)
EPROM (with UV light) erasable programmable read-only memory
EV Event messages
FB Function block
IF Interface designation
LCD Liquid-crystal display
LED Light-emitting diode
MPI Multitpoint Interface
OD Output double word (on the PLC)
OP Operator Panel
PLC Programmable Logic Controller
PPI Point to Point Interface
PU Programming Unit (German abbreviation: PG)
RAM Random access memory (working memory)
SRAM Static RAM (buffered)
VF Vacuum fluorescence
