Mechanical data
Nominal torque
Minimum holding torque (with operating voltage)
Minimum holding torque (no operating voltage)
Maximum torque
Nominal angle of rotation (with positioning indication)
Max. angle of rotation (mechanically limited)
Runtime for nominal angle of rotation 90°, Motor operation 50 Hz
Motor operation 60 Hz
Direction of rotation
(determined by signal control at wires 6 or 7)
Mechanical life
Dimensions for the damper shaft
Round
Square
Min. length
Max. shaft hardness
Actuator dimensions
Weight
35 Nm
> 35 Nm
> 35 Nm
< 75 Nm
90°
95°± 2°
150 s
125 s
clockwise/counter clockwise
10
5
cycles
8...25.6 mm
6...18 mm
20 mm
< 400 HV
see "Dimensions"
2 kg
Environmental conditions
Transport
Climatic conditions
Temperature
Humidity (non-condensing)
Mechanical conditions
Operation
Climatic conditions
Mounting location
Temperature
Humidity (non-condensing)
IEC 721-3-2
Class 2K2
−
32...+70 °C
< 95% r.h.
Class 2M3
IEC 721-3-3
Class 3K5
inside, weather-protected
−
32....+55
°C
< 95% r.h.
IP-Code
Housing type according to EN 60 529 IP 54
- Conformity
In accordance with the directives set forth by the European Union
Electromagnetic compatibility (EMC)
Low voltage directive
89/336/EEC
73/23/EEC
Product standards
Automatic electric regulating and controlling devices for residential use
and other applications (Type 1) EN 60 730-2-14
Electromagnetic compatibility
Emissions
Immunity
EN 50 081-1
EN 50 082-2
4626G01
A
100%
0%
(Y2)
AC 0 V
0...1000 W AC 24 V...230 V / 6 (2) A
GIB13...
(a)
(G)
(Q12)
(Q14)
(Q24)
(Q22)
1S2S3S5S6
7P3S1S4
(Q11)
(Q21)
B
(Y1)
(b)
(c)
6P1P2
AC 24 V
M
GBB13...
AC 24 V (SELV/PELV
)
4626G02
A
100%
0%
(Y2)
AC 230 V
0...1000
Ω
AC 24 V...230 V / 6 (2) A
GIB33...
(a)
(N)
(Q12)
(Q14)
(Q24)
(Q22)
4S2S3S5S6
7P3S1S4
(Q11)
(Q21)
B
(Y1)
(b)
(c)
6P1P2
M
GBB33...
AC 230 V
Diagrams
Internal diagrams
GIB131.1E
GIB135.1E
GIB136.1E
GIB331.1E
GIB335.1E
GIB336.1E
