5 / 10
Siemens PXG3... BACnet router for Ethernet - LONWORKS - MS/TP CM1N9270en_10
Building Technologies 2017-10-16
Engineering
• The router does not require programming. It is configured either using Xworks
Plus or the Desigo SSA-DNT via Ethernet or using a USB device. For details
see SSA (Setup & Service Assistant) Commissioning, CA111050).
• Each device has a unique identification number to ensure efficient
commissioning. The number is located on a removable barcode label.
• Each device has a unique MAC address.
For more details see document “Ethernet, TCP/IP, MS/TP and BACnet - Principles”
(CM110666).
Installation
Ethernet: See installation manual Desigo TRA, CM111043.
L
ONWORKS: See installation manual Desigo RXC, CA110336.
HMI (RJ45 plug): only the PXM20 can be connected. Otherwise the PXG3.L or the
mistakenly connected device may be damaged.
Mounting
The router is designed for mounting on a standard mounting rail or on a wall.
Power is supplied by connecting the plug-in screw terminal blocks.
Commissioning
To prevent equipment damage and/or personal injuries adhere to local safety
regulations and related safety standards.
Maintenance
No maintenance required. A supercap supports the real-time clock (3 days).
Disposal
The devices are considered electronic devices for disposal in terms of the
European Directive 2012/19/EU
(WEEE) and may not be disposed of as
domestic waste.
Dispose of the devices via the proper channels.
Observe all local and applicable laws.
