Mounting and installation
2
RF components
35
Siemens Operator / Room / Auxiliary devices CE1U2358en_04
Building Technologies 2014-09-26
NOTICE
●
The test is made to che
ck the quality of the radio link.
●
Testing takes place at the final installation location.
1. Press the button on the transmitter of the RF outside sensor between 3 and
max 8 seconds.
a The LED blinks slowly.
- When radio communications are operating correctly, the LED on the RF
module (AVS71.390) flashes briefly at 10-second intervals.
- With RF module BSB (AVS71.393), the LEDs go off every 10 seconds.
2. After checking, press again briefly the button on the transmitter of the RF
outside sensor until the LED extinguishes.
The test can be cancelled by pressing the ESC button.
Testing
