Siemens QAA75 series - 2.1.3 Operator unit AVS37.29 x

2
Mounting and installation
Wired components
14
Siemens Operator / Room / Auxiliary devices CE1U2358en_04
Building Technologies 2014-09-26
2.1.3 Operator unit AVS37.29x
Installation Removal
The AVS37.294 operator unit must be connected to terminal X30 of the basic unit
using the AVS82.491/109 connecting cable. The connectors are coded.
Installation
Connections
Dimensions
Panel cutout
