Siemens QAA75 series - 2.1.4 Operator unit AVS37.394

Mounting and installation
2
Wired components
15
Siemens Operator / Room / Auxiliary devices CE1U2358en_04
Building Technologies 2014-09-26
2.1.4 Operator unit AVS37.394
Siemens supplies operator unit AVS37.394 without a housing.
The AVS37.394 operator unit must be connected to terminal X30 on the basic unit
using the AVS82.491/109 connecting cable. The connectors are coded.
Dimensions
Connections
