3/12
Siem ens Room temperature controllers CE1N3072en
Building Technologies 2014-04-04
Ordering
Please provide the name and product number when ordering: Room temperature
controller RDJ10RF/SET.
Valves and actuators are ordered separately
Equipment combinations
Type of unit Product number Data sheet
*)
Electromotoric actuator SFA21... 4863
Electrothermal actuator (for radiator valves) STA21... 4877
Electrothermal actuator (for small valves 2.5 mm) STP21... 4878
2- or 3-port zone valve MXI/MVI421… 4867
Electromotoric actuator for zone valves V..146.. SUA21 4830
Electric actuator SUA11/22 4832
Air damper actuator GDB… 4624
Air damper actuator GSD/GQD… 4606
Air damper actuator GXD… 4622
*) The documents can be downloaded from http://siemens.com/bt/download.
Mechanical design
The unit consists of 4 parts:
· Plastic housing with digital display accommodating the electronics, operating
elements and built-in room temperatures sensor
· Baseplate (mounting base)
· Removable battery compartment
· Fold-out stand
The housing engages in the baseplate and snaps on. There is a reset button on the
rear of the unit.

Siemens RCR10/433 Specifications

General

Operating Voltage	230 V AC
Temperature Setting Range	5°C to 30°C
Control Type	On/Off
Type	Room Thermostat
Power Supply	230 V AC
Protection Class	IP30
Frequency	50 Hz
Mounting Type	Wall
Switching Current	10 (4) A
Accuracy	±1°C
